Instant strong power, rapid acceleration
High rate shockproof, no high-speed decay
Fast charging efficient, durable adaptable
| Serial No. | Item | Required Parameters | Remarks |
|---|---|---|---|
| 1 | Nominal Capacity | 75Ah | |
| 2 | Nominal Voltage | 73V | 20S |
| 3 | Electric Quantity | 5475Wh | |
| 4 | Charge Cut-off Voltage | 84V | |
| 5 | Discharge Cut-off Voltage | 55V | |
| 6 | Standard Charging Current | 24.7A | |
| 7 | Maximum Charging Current | 75A | |
| 8 | Standard Discharging Current | 24.7A | |
| 9 | Maximum Discharging Current | 160A | |
| 10 | Charging Operating Temperature | 0~45℃ | |
| 11 | Discharging Operating Temperature | -20~55℃ | |
| 12 | Charging Interface | Cable Gland | |
| 13 | Discharging Interface | Cable Gland | |
| 14 | BMS Requirements | BMS Required | |
| 15 | Outer Shell | Sheet Metal Shell | |
| 16 | Other Special Requirements | None | |
| 17 | Dimensions (≤) | 225×210×404±3mm | Length*Width*Height |
| 18 | Weight (≤) | 28±0.5kg |
