Sold out
Roll over or click image to zoom in
Stable power
industrial-ready
Smart protection,
High-current, long cycle life
| Serial No. | Item | Required Parameters | Remarks |
|---|---|---|---|
| 1 | Nominal Capacity | 314Ah | |
| 2 | Nominal Voltage | 51.2V | 16S |
| 3 | Electric Quantity | 16076Wh | |
| 4 | Charge Cut-off Voltage | 58.4V | 95% DOD |
| 5 | Discharge Cut-off Voltage | 44.8V | |
| 6 | Standard Charging Current | 60A | |
| 7 | Continuous Charging Current | 100A | |
| 8 | Charging Operating Temperature | 0~45℃ | |
| 9 | Discharging Operating Temperature | -20~55℃ | |
| 10 | Charging Interface | Anderson 120A Plug | 16mm² Wire Harness, 500mm Wire Length |
| 11 | Discharging Interface | Anderson 175A Plug | 35mm² Wire Harness, 500mm Wire Length |
| 12 | BMS Requirements | With Communication; Equipped with Overcharge, Over-discharge, Temperature Protection, etc. | |
| 13 | Outer Shell | Sheet Metal | |
| 14 | Dimensions (≤) | 5227×504×760±5mm | |
| 15 | Weight (≤) | 130±5kg |
