Sold out
Roll over or click image to zoom in
Long range stable
Large capacity energy-saving
boat-ready
Waterproof durable
efficient refueling
| Serial No. | Item | Required Parameters | Remarks |
|---|---|---|---|
| 1 | Nominal Capacity | 146Ah | IMP14294105P73D |
| 2 | Nominal Voltage | 74V | 20S |
| 3 | Electric Quantity | 10804Wh | |
| 4 | Charge Cut-off Voltage | 84V | |
| 5 | Discharge Cut-off Voltage | 55V | |
| 6 | Standard Charging Current | 50A | |
| 7 | Maximum Charging Current | 73A | |
| 8 | Maximum Continuous Discharging Current | 260A | |
| 9 | Maximum Pulse Discharging Current | 500A@10s | |
| 10 | Charging Operating Temperature | 0~45℃ | |
| 11 | Discharging Operating Temperature | -20~55℃ | |
| 12 | Charging Interface | Shared Charging & Discharging Interface | |
| 13 | Discharging Interface | Shared Charging & Discharging Interface | |
| 14 | BMS Requirements | Supports Bluetooth Connection | |
| 15 | Outer Shell | Aluminum Alloy (Overall IP67 Protection) | |
| 16 | Other Special Requirements | Metal Button Switch Controls Discharging | Switch Supports IP67; Switch Tail Sealed with Glue |
| 17 | Dimensions (≤) | 586×379×130±2mm | Length*Width*Height (Including Wall Thickness, Excluding Flange) |
| 18 | Weight (≤) | 46±0.5kg |
