Long battery life
High Energy Density
High safety
High cycle life
Fast charging efficiency
Adaptability and stability
Lightweight design
Customized Solutions
| Serial No. | Item | Required Parameters | Remarks |
|---|---|---|---|
| 1 | Nominal Capacity | 30Ah | |
| 2 | Nominal Voltage | 44.4V | |
| 3 | Electric Quantity | 1332Wh | |
| 4 | Charge Cut-off Voltage | 51V | |
| 5 | Discharge Cut-off Voltage | 36V | 95% DOD |
| 6 | Standard Charging Current | 15A | |
| 7 | Maximum Charging Current | 30A | |
| 8 | Continuous Discharging Current | 90A | Continuous 3C |
| 9 | Maximum Pulse Discharging Current | 240A@10s | Instant 8C |
| 10 | Charging Operating Temperature | 0~45℃ | |
| 11 | Discharging Operating Temperature | -20~55℃ | |
| 12 | Charging Interface | MOLEX-430251600 Connector | |
| 13 | Discharging Interface | AS150U-8AWG | |
| 14 | Outer Shell | PVC Heat Shrink Film Soft Package | |
| 15 | Dimensions (≤) | 205×90×120±2mm | Height*Width*Thickness |
| 16 | Weight (≤) | 4.5±0.2kg | |
| Other Capacities: 10Ah/12Ah/16Ah/22Ah/28Ah, etc. | |||
