High Energy Density
Flexible Combination for Multiple Needs
Outstanding High & Low Temperature Resistance
Adaptation to Complex Working Conditions
Customized Solutions
| Serial No. | Item | Required Parameters | Remarks |
|---|---|---|---|
| 1 | Nominal Capacity | 70Ah | |
| 2 | Nominal Voltage | 74V | |
| 3 | Electric Quantity | 5180Wh | |
| 4 | Charge Cut-off Voltage | 84V | |
| 5 | Discharge Cut-off Voltage | 60V | |
| 6 | Standard Charging Current | 35A | |
| 7 | Maximum Charging Current | 70A | |
| 8 | Continuous Discharging Current | 210A | Continuous 3C |
| 9 | Maximum Pulse Discharging Current | 700A@10s | Instant 10C |
| 10 | Charging Operating Temperature | 0~45℃ | |
| 11 | Discharging Operating Temperature | -20~55℃ | |
| 12 | Charging Interface | MOLEX-430251600 Connector | |
| 13 | Discharging Interface | QS10P-L Connector, 6AWG Red & Black Silicone Wire | |
| 14 | Outer Shell | PVC Film Heat Shrink Soft Package | |
| 15 | Dimensions (≤) | 210×180×230±2mm | Height*Width*Thickness |
| 16 | Weight (≤) | 17.5±0.1kg | |
| Other Capacities: 20Ah/25Ah/32Ah/35h/40Ah, etc. | |||
